Model Number
M2-650DS-A1
65" Digital Signage Touch Monitor
Description
The new M2-650DS-A1 65″ interactive touch monitor is a newly designed solution for a variety of applications. Engineered with optical bonding between the sensor and LCD, improving optical clarity, adding strength and impact resistance, while increasing touch accuracy. The M2-650DS-A1 features a premier anti-glare finish, driving better light dispersion and viewing performance in high ambient light applications. Supporting more than 55 touch points, multiple styli and erasers, this display is a drop-in solution for not only retail/hospitality signage and wayfinding, but collaboration applications as well. Combining the ultra-slim design, enhanced anti-glare finish, the versatile I/O selection, peak optical performance with 4k resolution, this display is a solution that can exceed a wide range of application requirements.
Featured Specifications
- Size: 65" TFT LCD
- Maximum Resolution: 3840 x 2160
- Contrast Ratio: 1200:1
- Aspect Ratio: 16:9
- Brightness: 500 nits (No Touch), 450 nits (P-CAP)
- View Angle: H: 178˚, V: 178˚
- Video Port: 2 x HDMI/1 x DisplayPort/ 1 x VGA
- Compliance: TAA
- Warranty: 3 Year
Resources
Specifications
Touch LCD Display
Touch Screen: Projected Capacitive
Touch Points: >55 (with stylus support)
Touch Screen Interface: USB-HID (Type B)
Surface Treatment: Anti-Glare, Optical Bonding
I/O Ports
Serial Port: 1 x RS232 (DB9)
USB Port: 2 x USB Type B (touch), 1 x USB 2.0 Type A
Video Port: 2 x HDMI / 1 x DisplayPort / 1 x VGA
Audio Port: PC Audio in/out, SPDIF out
Network Port: 1 x RJ45
Power Input: AC Input 100~240Vac, 50~60Hz
Power Output: AC output IEC C13 type
Physical Properties
Power Supply: 255 W Typ.
Speaker: 10W x 2
Orientation: Portrait/Landscape/Tabletop
Housing Color: Black
Construction: Glass, SECC Metal
Compliance: IP65 – Front only
Dimensions (W x H x D) mm: 1493.2 x 868.24 x 89.9 mm
Net Weight (kg): 36 kg
Carton (W x H x D) mm: 1378 x 874 x 185 mm
VESA: 600 x 400 mm
Ball Drop: IK06
Safety
Certifications: FCC/CE/UL/CEC/UKCA/ETSI EN 303 645
Environment
Operating Temperature: 0˚C ~ 40˚C, 35% ~ 85%, RH. Non-Condensing
Storage Temperature: -20˚C ~ 60˚C, 35% ~ 85% RH. Non-Condensing
